Ribbon Coding machine
Item No.: HP-241B
It can print on plastic film, aluminum foil, plastic bags, thin cardboard, paper sheets, leather, etc.
Adopt color ribbon printing, characterized by high definition, instant dryness, and non-stickiness.
Origin: Anhui, China
Model: HP-241B
HS code: 84
Adopt color ribbon printing, characterized by high definition, instant dryness, and non-stickiness.
Origin: Anhui, China
Model: HP-241B
HS code: 84
Description
HP-241B Ribbon Coding Machine
It can print on plastic film, aluminum foil, plastic bags, thin cardboard, paper sheets, leather, etc.Adopt color ribbon printing, characterized by high definition, instant dryness, and non-stickiness.
Adopt constant temperature control with adjustable temperature, suitable for color ribbons made from different kinds of materials.
It can print continuously and automatically or print through the pedal switch.
There are 2 kinds of printers to choose between LH-380 (solid ink wheel printer) and HP-210 (hot ribbon code printer). The ink-wheel printer has a higher printing speed. However, the print clarity of the ink wheel is not as fast as the ribbon. The printed writing of the ribbon printer is firmer than the ink-wheel printer.
Black Ribbon
Color ribbons are printer consumables. It is suitable for AL/PP/PET/PE/PVC and other soft material product print production date and batch number.
Size | 30mm*100m |
Print times | < 10,000 |
Temperature range | 110-180℃ |
Copper letter and number
The copper sculpture, durable, 2*4*15mm, the free copper heads listName | Qty. | Name | Qty. | Name | Qty. | Name | Qty. | Name | Qty. | Name | Qty. | Name | Qty. |
0 | six | 1 | five | 2 | five | 3 | four | 4 | two | 5 | two | 6 | four |
7 | two | 8 | two | 9 | four | . | two | / | two | Blank | ten | : | three |
M | one | F | one | G | one | E | one | X | one | P | one | B | one |
A | one | T | one | C | one | H | one | N | one | O | one |
Printed sample
BATCHNO: 20240308
MFG:08/03/2024
EXP:07/03/2025
MFG:08/03/2024
EXP:07/03/2025
Technical data
Driven Type | Electric | |
Power supply | AC 220 ± 10V, 50/60Hz | |
Power | 220 W | |
Packaging Material | Soft Plastic, Aluminum foil | |
Thickness | ≤ 4 mm | |
Printing speed | 20-100 times/min, Stepless adjustable | |
Working temperature | 0-200℃ | |
Printing Quantity | 1 Line | 2×4mm Max. 12 Types |
2 Lines | 2×4mm Max. 24 Types | |
3 Lines | 2×4mm Max. 36 Types | |
Color Ribbon Width | 30mm*100m | |
Dimension | 350×350×350(mm) (L×W×H) | |
Weight | 15 kg | |
Warranty | 1 year | |
Packaging | Carton box |
